Product Details:
Payment & Shipping Terms:
|
Material: | Steel Q235/Q345, Steel Q235/245 | Finish: | Corrosion Protection |
---|---|---|---|
Size: | Customzied | Structure: | Assemble Or Welded |
Weight Capacity: | Maximum 1500kg/pallet | Store Layer:: | 1 To 7 Layers Per Bay |
Technique: | Cold Rolled | Color: | Ral Color System |
Highlight: | Customzied Drive In Pallet Racking,Cold Rolled Drive In Pallet Racking,Warehouse Drive In Storage Rack |
Exported Oversea Drive in Pallet Racking Warehouse Storage Made in China
Description:
1. Drive in rack system is last in first out store system. Suits for unified palletized goods.
2. Drive in rack system is a high density store system. It can use most of the warehouse space. So it can save space, save store cost. In the same area, push back rack can store much more goods.
3. Push back rack system doesn't need forklift to go into its lanes, so enhance safety for forklift operator.
Features:
1. Maximized space utilization.
2. Improved SKU management.
3. Less on-hand inventory and more inventory turns.
4. More efficient picking abilities with less chance of errors.
5. Improved on-time product delivery by consolidating orders with less errors.
6. Increased product protection.
7. Reduced labor costs.
8. Increased throughput and flow.
9. Improved safety.
10. Improved facility layout and appearance.
11. Improved ergonomics and reduced worker fatigue.
Product Name
|
Cold Rolled Steel coils Heavy Duty colorful drive in Rack made from steel |
Material
|
Steel Q235
|
Loading Capacity
|
Customized and up to 4,000 Kg UDL/level
|
Racking Height
|
Customized and up to 11,000 mm
|
Racking Depth
|
700-1,200 mm
|
Beam Length
|
Customized and up to 3,600 mm
|
Racking Finish
|
Frames (Powder Coated or Pre-galvanized) + Bracings (Powder Coated or Pre-galvanized) + Beams (Powder coated)
|
Packing Details
|
Standard export seaworthy packing
|
Specifications of Upright
|
||||
Item
|
Width(mm)
|
Depth(mm)
|
Thickness(mm)
|
Loading Capacity(kg)
|
1
|
85
|
67
|
1.6
|
7000
|
2
|
85
|
67
|
1.8
|
8500
|
3
|
85
|
67
|
2.0
|
10000
|
4
|
85
|
67
|
2.3
|
12500
|
5
|
100
|
67
|
1.8
|
10500
|
6
|
100
|
67
|
2.0
|
12000
|
7
|
100
|
67
|
2.3
|
13800
|
8
|
100
|
95
|
2.0
|
12000
|
9
|
100
|
95
|
2.3
|
14500
|
10
|
100
|
95
|
2.5
|
16000
|
11
|
100
|
95
|
2.75
|
18000
|
12
|
100
|
95
|
3.0
|
20000
|
13
|
120
|
95
|
2.5
|
17000
|
14
|
120
|
95
|
2.75
|
19000
|
15
|
120
|
95
|
3.0
|
21000
|
Frames:Product Details
Frames are made up of two uprights with the corresponding horizontal& diagonal bracings, footplates and accessories.
The frames have slots every 75mm to accommodate the beams and supports.
