Custom Medium Duty Storage Rack Assemble / Welded Structural Steel Pallet Rack Manufacturers

Custom Medium Duty Storage Rack Assemble / Welded Structural Steel Pallet Rack Manufacturers
Custom Medium Duty Storage Rack Assemble / Welded Structural Steel Pallet Rack Manufacturers Custom Medium Duty Storage Rack Assemble / Welded Structural Steel Pallet Rack Manufacturers Custom Medium Duty Storage Rack Assemble / Welded Structural Steel Pallet Rack Manufacturers Custom Medium Duty Storage Rack Assemble / Welded Structural Steel Pallet Rack Manufacturers

Large Image :  Custom Medium Duty Storage Rack Assemble / Welded Structural Steel Pallet Rack Manufacturers

Product Details:
Certification: ISO9001/14001
Model Number: W-MD2017522-6
Payment & Shipping Terms:
Minimum Order Quantity: 20 Sets
Price: Negotiation
Packaging Details: Standard export carton with bubble film
Delivery Time: 15-30 Days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 3500 Ton/Tons per Month
Detailed Product Description
Material: Steel Q235/Q345, Steel Q235/245 Finish: Corrosion Protection
Size: Customzied Structure: Assemble Or Welded
Type: Heavy Duty Storage Racks For Outdoor And Inside Warehouse Color: Customized RAL Color
Feature: Corrosion Protection, Adjustable Weight Capacity: 1000kg/pallet
Highlight:

Custom Medium Duty Storage Rack

,

Medium Duty Storage Rack Manufacturers

,

Structural Steel Pallet Rack Manufacturers

Customized Factory Warehouse Medium Duty Storage Rack for Goods Storage



Advantages of warehouse storage pallet racking :

• Indibidual access to all pallet to full height of warehouse.

• Simple stock rotation achieved

• Easy beam adjustment

• Compatible with many handling equipment style.

• Economical shelving beams can be added for level picking



Description:



Middle Duty Storage Racks, structured with pallets and beams are most widely used in warehouse industry. This kind of steel middle duty racking is widely used together with forklifts , steel storage containers, steel pallets and storage boxes.



Each level can be adjustable at 75mm per pitch and the maxmum loading is 25000kg with the maxmum length of 12 meters; Each level loading duty is from 200kgs to 500kgs, depending on the beam length. Pallets made of different material with various sizes, can be used on practical stackable pallet racks.



Features:

1. Anti-slip rubber inserted;

2. Upright frame include 2 uprights, several bracing and Bolts.

3. Color: Blue, other colors accroding to clients' request.

4. Racking surface treatment is static powder coating;



Product Name
Customized Factory Warehouse Medium Duty Storage Rack for Goods Storage
Products Description
1). Upright: 55*45mm, 90*65mm
Thickness: 1.5mm, 2.0mm
2). Dimension : L 2000-2700 X W800-1200 X H3000-7000mm.
"P" Beam: 80*45*1.5mm, 100*45*1.5mm
3). Material : High grade of cold rolled steel .
4). Weight capability : 200-500kg/layer .
5). Different dimension ,weight capability are available for us .
6). Can Design According to Customers Warehouse Layou





Custom Medium Duty Storage Rack Assemble / Welded Structural Steel Pallet Rack Manufacturers 0

Specification:



S/N Standard Size(W*D*H) Loading Weight Standard Layer Material
1 2300*900*3000 200-500kg/level 2+1(ground) steel
2300*900*4000 3+1(ground)
2300*1000*3000 2+1(ground)
2300*1000*4000 3+1(ground)
2 2500*900*3500 2+1(ground)
2500*900*4000 3+1(ground)
2500*1000*3500 2+1(ground)
2500*1000*4000 3+1(ground)
3 2700*900*3500 2+1(ground)
2700*900*4000 3+1(ground)
2700*900*5000 3+1(ground)
2700*900*6000 4+1(ground)
2700*1000*3500 2+1(ground)
2700*1000*4000 3+1(ground)
2700*1000*5000 3+1(ground)
2700-5000*1000*6000-12000 (4,5,6...)+1(ground)
Remark:This size is our standard only. Different size with various loading weight and levels are acceptable.



Please kindly provide the below to us for quotation of heavy duty pallet racking :

• the CAD drawing of the warehouse (if available);

• the sizes and weight of the pallet (length, width, height)

• the size of the warehouse (length, width, clear height)

• the layers of each shelf

• the color that you want;

• the loading weight of each layer

• WE WILL PROVIDE Competitive price, GOOD QUALITY
