Name: Safety lock High Density Mobile File Storage System , Compactus Filing System
Brand: Dongguan Zhijia Storage Equipment Co.,Ltd.
SKU: W-MFC2017526
Price: 115.00 USD
Availability: InStock

Home > Products > Moving File Cabinets Shelf System >

Safety lock High Density Mobile File Storage System , Compactus Filing System

ISO9001 High Density Mobile File Storage System

Safety lock High Density Storage Shelves

Compactus Filing System

Certification:

ISO9001/14001

Model Number:

W-MFC2017526

Request A Quote

Safety lock High Density Mobile File Storage System , Compactus Filing System

Product Details

Product Name:

High Density Storage Shelves

Raw Material:

High Qulity Cold Roll Steel

Structure:

Knock Down / Easy Assemble

Lock:

Safety Lock And 3-point Key Lock

Layer Of Each bay:

6 Layers Or Customized

Color:

Grey

Certification:

ISO90001/ISO14001

Advantage:

Factory Price

Highlight:

ISO9001 High Density Mobile File Storage System

Safety lock High Density Storage Shelves

Compactus Filing System

Payment & Shipping Terms

Minimum Order Quantity

2-10 SETS

Price

Negotiation

Packaging Details

Professional & Saft packaging for oversea shipment

Delivery Time

15-30 Days

Payment Terms

L/C, T/T, Western Union

Supply Ability

100 SETS

Mobile Grey File Cabinets With Safety Lock 200 Lbs Capacity Corrosion Protection Shelf System

Get Best Price

200 Lbs Steel Filing Cabinet Shelf System With Corrosion Protection

Get Best Price

Grey Steel Moving File Cabinets With Safety Lock Adjustable Shelves 200 Lbs Weight Capacity

Get Best Price

Secure Grey Steel File Cabinet With Adjustable Shelves Safety Lock And 3 Point Key Lock

Get Best Price

+86 0769-83726626

vivian@good-shelf.cn

Contact Now

Product Description

Easy Assemble 3-Point Key Lock 6 Layers Powder Coating Movable Cabinet

Description:

Movable Cabinet is a cost effective way of increasing storage capacity and utilizing valuable floor space, which can double storage capacity compared to conventional static shelving.
It is widely used in offices for file storage and are designed to be easily re-located with no floor fixing. It moves along floor tracks allowing the aisle to be moved so that the required shelves can be accessed, so only one aisle is needed.

Features:

Raw material:High Qulity Cold Roll Steel

Structure:Knock down,easy assemble

Lock:Safety lock and 3-point key lock

Layer of each:bay 6 layers or customized

Thickness:0.8-2.5mm

Surface:Electrostatic Powder Coating

Spare parts:As your requirement

Color:grey

Zhijia Service:

Solution:Available for free

ODM&OEM:Available

Certification:ISO90001/ISO14001

Warranty:warranty 5 years

Business Type:Manufacturer

Advantage:Factory price

Response time:30 mins

Specification:

Shelf body	Stand Column	Cold-roll steel	1.5mm	GB708
	Partition Whole body partition partition flange 25mm (reinforcing rib under the partition)	Cold-roll steel	1.0mm	GB708
	Side plate	Cold-roll steel	1.0mm	GB708
	Upper cover plate (whole body side plate dimension 300X100mm)	Cold-roll steel	1.0mm	GB708
	Panel	Cold-roll steel	1.0mm	GB708
chassis	Main beam and whole frame board	Hot rolled steel plate	3.0mm	GB710
chassis	(every wheelo frame board have six : 55mm beam bush hole. every hole have sealing	Hot rolled steel plate	3.0mm	GB710
pathway	Rail	High quality steel plate	Solid square tube	GB710
	Rail box	High quality steel plate	26X95mm	GB710
	Rail box	High quality steel plate	Thickness 3.0	GB710
	Pathway	High quality steel plate	50X185	GB710
	Pathway	High quality steel plate	Thickness 3.0	GB710
Transmission part	Handle crank	ZG45	Bothway overload clutch	GB1285
	Handle crank	ZG45	double axis transmission	GB1285
	Transmission shaft	Solid core 45 steel	Φ20	GB699
	Linkage rail	Seamless steel tube	Φ20X2.5	GB699
	Bearing	Precision bearing	HR6204	GB/T
	Bearing	Precision bearing	HR6204	307.3-2005
	Chain wheel	ZG45		GB1135
	Chain	FR420	Φ8.5, pitch12.7	GB1244
	Chain	FR420	breaking force 1800kg	GB1244
	Idler wheel	HT20-40	Cast iron	Gb11351
	Sealing rubber strip	Magnetic fluid sealant
	Dust shield	Cold-roll steel	1	Gb710
	Barb	Hot rolled steel plate	3.0mm	Gb711
