Cold Rolled Steel Drive In Drive Through Racking System For Industrial Warehouse

Cold Rolled Steel Drive In Drive Through Racking System For Industrial Warehouse

    • Cold Rolled Steel Drive In Drive Through Racking System For Industrial Warehouse
    • Cold Rolled Steel Drive In Drive Through Racking System For Industrial Warehouse
    • Cold Rolled Steel Drive In Drive Through Racking System For Industrial Warehouse
    • Cold Rolled Steel Drive In Drive Through Racking System For Industrial Warehouse
  • Cold Rolled Steel Drive In Drive Through Racking System For Industrial Warehouse

    Product Details:

    Place of Origin: Dong Guan, China
    Brand Name: Zhijia
    Certification: ISO9001/14001
    Model Number: W-DR2017523

    Payment & Shipping Terms:

    Minimum Order Quantity: 20 Sets
    Price: Negotiation
    Packaging Details: Standard export carton with bubble film
    Delivery Time: 15-30 Days
    Payment Terms: T/T, Western Union, L/C
    Supply Ability: 3500 Ton/Tons per Month
    Contact Now
    Detailed Product Description
    Material: Steel Q235/Q345, Steel Q235/245 Finish: Corrosion Protection
    Size: Customzied Structure: Assemble Or Welded
    Weight Capacity: Maximum 1500kg/pallet Store Layer:: 1 To 7 Layers Per Bay
    Technique: Cold Rolled Color: Ral Color System

    Cold Rolled Steel coils Heavy Duty colorful drive in Rack made from steel



    Description:



    Drive-In Rack optimizing available space. Elimination of aisles between shelves. Admits as many references as load lanes. Appropriate system to store homogeneous, low-rotation products with a large number of pallets per reference.



    1. Drive in rack system is last in first out store system. Suits for unified palletized goods.

    2. Drive in rack system is a high density store system. It can use most of the warehouse space. So it can save space, save store cost. In the same area, push back rack can store much more goods.

    3. Push back rack system doesn't need forklift to go into its lanes, so enhance safety for forklift operator.

    Zhijia-drive in layout plan.pdf

    Freezing Room B,D Drive In Rack-ZJ.pdf





    Features:



    1. Maximized space utilization.

    2. Improved SKU management.

    3. More efficient picking abilities with less chance of errors.

    4. Less on-hand inventory and more inventory turns.

    5. Improved on-time product delivery by consolidating orders with less errors.

    6. Increased product protection.

    7. Reduced labor costs.

    8. Increased throughput and flow.

    9. Improved safety.

    10. Improved facility layout and appearance.

    11. Improved ergonomics and reduced worker fatigue.



    Product Name

    Cold Rolled Steel coils Heavy Duty colorful drive in Rack made from steel

    Material
    Steel Q235
    Loading Capacity
    Customized and up to 4,000 Kg UDL/level
    Racking Height
    Customized and up to 11,000 mm
    Racking Depth
    700-1,200 mm
    Beam Length
    Customized and up to 3,600 mm
    Racking Finish
    Frames (Powder Coated or Pre-galvanized) + Bracings (Powder Coated or Pre-galvanized) + Beams (Powder coated)
    Packing Details
    Standard export seaworthy packing



    Specifications of Upright
    Item
    Width(mm)
    Depth(mm)
    Thickness(mm)
    Loading Capacity(kg)
    1
    85
    67
    1.6
    7000
    2
    85
    67
    1.8
    8500
    3
    85
    67
    2.0
    10000
    4
    85
    67
    2.3
    12500
    5
    100
    67
    1.8
    10500
    6
    100
    67
    2.0
    12000
    7
    100
    67
    2.3
    13800
    8
    100
    95
    2.0
    12000
    9
    100
    95
    2.3
    14500
    10
    100
    95
    2.5
    16000
    11
    100
    95
    2.75
    18000
    12
    100
    95
    3.0
    20000
    13
    120
    95
    2.5
    17000
    14
    120
    95
    2.75
    19000
    15
    120
    95
    3.0
    21000



    Cold Rolled Steel Drive In Drive Through Racking System For Industrial Warehouse



    Cold Rolled Steel Drive In Drive Through Racking System For Industrial Warehouse



    Cold Rolled Steel Drive In Drive Through Racking System For Industrial Warehouse


    Frames:Product Details



    Frames are made up of two uprights with the corresponding horizontal& diagonal bracings, footplates and accessories.
    The frames have slots every 75mm to accommodate the beams and supports.


    Arms:
    There are two types of arms, which are single arm (left side and right side single arms) and double arm. The single arm is used in each side of the racks, while the double arm is used in between.

    Pallet Support Rails:
    Support rails are stamp formed and the length can be customized. The rails are designed without connectors to ensure uniform loading.



    Top beams and top bracings:
    Top beams and top bracings are used to increase integrity and stability of the racking system.

    Shipping:
    Cold Rolled Steel Drive In Drive Through Racking System For Industrial Warehouse
