3-Point Key Lock Mobile Shelving Systems / High Density Storage Systems

3-Point Key Lock Mobile Shelving Systems / High Density Storage Systems
3-Point Key Lock Mobile Shelving Systems / High Density Storage Systems 3-Point Key Lock Mobile Shelving Systems / High Density Storage Systems

Large Image :  3-Point Key Lock Mobile Shelving Systems / High Density Storage Systems

Product Details:
Certification: ISO9001/14001
Model Number: W-MFC2017526
Payment & Shipping Terms:
Minimum Order Quantity: 2-10 SETS
Price: Negotiation
Packaging Details: Professional & Saft packaging for oversea shipment
Delivery Time: 15-30 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 SETS
Detailed Product Description
Product Name: High Density Storage Systems ManufacturersHigh Density Storage Systems Manufacturers Raw Material: High Qulity Cold Roll Steel
Structure: Knock Down、easy Assemble Lock: Safety Lock And 3-point Key Lock
Layer Of Each bay: 6 Layers Or Customized Thickness: 0.8-2.5mm
ODM&OEM: Available Solution: Available For Free
High Light:

high density mobile shelving

,

rolling shelving systems

Knock Down 3-Point Key Lock High Density Storage Systems Manufacturers



Description:



High density storage systems manufacturers offers the highest possible density for storing files and other goods. Mobile shelving systems maximize existing storage space by eliminating aisles and compacting several storage cabinets or shelving systems into a much smaller amount of space. An aisle or access to your files is opened up only when and where you need it by easily shifting entire rows of high-density shelving



Features:



Raw material:High Qulity Cold Roll Steel

Structure:Knock down,easy assemble

Lock:Safety lock and 3-point key lock

Layer of each:bay 6 layers or customized

Thickness:0.8-2.5mm

Surface:Electrostatic Powder Coating

Spare parts:As your requirement

Color:grey

Zhijia Service:



Solution:Available for free

ODM&OEM:Available

Certification:ISO90001/ISO14001

Warranty:warranty 5 years

Business Type:Manufacturer

Advantage:Factory price

Response time:30 mins





Specification:



Shelf body Stand Column Cold-roll steel 1.5mm GB708
Partition Whole body partition partition flange 25mm (reinforcing rib under the partition) Cold-roll steel 1.0mm GB708
Side plate Cold-roll steel 1.0mm GB708
Upper cover plate (whole body side plate dimension 300X100mm) Cold-roll steel 1.0mm GB708
Panel Cold-roll steel 1.0mm GB708
chassis Main beam and whole frame board Hot rolled steel plate 3.0mm GB710
(every wheelo frame board have six : 55mm beam bush hole. every hole have sealing
pathway Rail High quality steel plate Solid square tube GB710
Rail box High quality steel plate 26X95mm GB710
Thickness 3.0
Pathway High quality steel plate 50X185 GB710
Thickness 3.0
Transmission part Handle crank ZG45 Bothway overload clutch GB1285
double axis transmission
Transmission shaft Solid core 45 steel Φ20 GB699
Linkage rail Seamless steel tube Φ20X2.5 GB699
Bearing Precision bearing HR6204 GB/T
307.3-2005
Chain wheel ZG45   GB1135
Chain FR420 Φ8.5, pitch12.7 GB1244
breaking force 1800kg
Idler wheel HT20-40 Cast iron Gb11351
  Sealing rubber strip Magnetic fluid sealant
Dust shield Cold-roll steel 1 Gb710
Barb Hot rolled steel plate 3.0mm Gb711





3-Point Key Lock Mobile Shelving Systems / High Density Storage Systems 03-Point Key Lock Mobile Shelving Systems / High Density Storage Systems 13-Point Key Lock Mobile Shelving Systems / High Density Storage Systems 2
