Cold Rolled Structure Steel Drive In Racking System For Drum Type Objects Storage

China Dongguan Zhijia Storage Equipment Co.,Ltd. certification
China Dongguan Zhijia Storage Equipment Co.,Ltd. certification
Thank you for you mail. We are seeking approval from management.Thank you for your cooperation.

—— Howard

Your products use well.

—— Helen

The drawing is accurate, please provide quotation.

—— Michael

I'm Online Chat Now

Cold Rolled Structure Steel Drive In Racking System For Drum Type Objects Storage

Cold Rolled Structure Steel Drive In Racking System For Drum Type Objects Storage
Cold Rolled Structure Steel Drive In Racking System For Drum Type Objects Storage Cold Rolled Structure Steel Drive In Racking System For Drum Type Objects Storage Cold Rolled Structure Steel Drive In Racking System For Drum Type Objects Storage Cold Rolled Structure Steel Drive In Racking System For Drum Type Objects Storage

Large Image :  Cold Rolled Structure Steel Drive In Racking System For Drum Type Objects Storage

Product Details:
Certification: AS4084
Model Number: ZJ-DR2017525
Payment & Shipping Terms:
Minimum Order Quantity: 10 Sets
Price: Negotiation
Packaging Details: Standard export carton with bubble film
Delivery Time: 15-30 Days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 350 Ton/Tons per Month
Detailed Product Description
Name: Drive In Racking System Material: Steel Q235B
Finish: Corrosion Protection Size: Customzied
Structure: Assemble Weight Capacity: Maximum 4000kg/lever
Store Layer:: 1 To 7 Layers Per Bay Technique: Cold Rolled
High Light:

Cold Rolled Drive In Racking System

,

Structure Steel Drive In Racking System

Cold Rolled Structure Steel Drive In Pallet Racking for Drum-type Objects Store


Drive-in Pallet Rack Features:
Allows your forklift truck to drive into accessible lanes

Perfect for high density storage of largely similar items

Prevents product crushing, and offers damage free storage

Floor single or double stacked pallets always accessible

No special forklift needed

Designing factors:
How high (4000mm, 5000mm or 6000mm) -- most popular is 5000mm

What’s your pallet size and load capacity per pallet?

How many pallet rail levels (3, 4 or 5) -- most popular is 3+1=4 levels

Your forklift turning radius need calculate proper passageway?

If possible send us your warehouse layout so that we can set up designing

Description:

Drive-In & Drive-Through Racks offer the ability to store a large amount of similar loads in a smaller area. Selectivity is sacrificed, but storage density is outstanding. Drive In Racking can store up to 75% more pallets in the same space than selective racking -- depending on your application. It requires fewer aisles and is better cubic storage.
A simple way to identify a Drive-In Rack Systems is its LIFO inventory management. Product is rotated in a Last-In, First-Out inventory manner because of the single entry/exit point.
Drive-In Rack optimizing available space. Elimination of aisles between shelves. Admits as many references as load lanes. Appropriate system to store homogeneous, low-rotation products with a large number of pallets per reference.

This system is base on the storage by accumulation principle, which enables the highest use of available space in terms of both area and height. Drive-in racking is designed for the storage of homogeneous products. It accommodates a large number of pallets.
Drive-In Rack and Drive-Thru racking are terms that are often used interchangeably. In some environments it can be difficult to differentiate between the two. Typically, Drive-In racking requires operators to drive into the racking system from one side and remove pallets from the same entry point. Some Drive-In rack systems have a wall or are otherwise closed at the opposite end.


Features:


Product Name Drive In Pallet Racks
Customized Specification Drive-in Racking is available in a range of sizes and configurations. Please call or email us and we can work together to get the most cost-effective and practical solution.
Pallet Rail Levels 2 levels, 3 levels, 4 levels, 5 levels
Load Capacity per Pallet 500KG, 800KG, 1200KG, 1500KG, 2000KG
Raw Material high quality cold rolling steel Q235B(SS400) purchased from Shanghai Baosteel Group
Material Thickness 1.5mm, 1.8mm, 2.0mm, 2.5mm
Surface Treatment deoil, derusting and powder coat paint finish
Rack Colors standard blue, orange and customized available
HS Code 7308900000





Our Service:
If you want to get quick quotation on Drive-in Rack,much better let us know your storage needs or details of your warehouse project.Accordingly,we'll be happy to provide with our professional proposed racking solutions,drawings & quotations for your kind reference.



Cold Rolled Structure Steel Drive In Racking System For Drum Type Objects Storage 0



FAQ:
1. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Dongguan City, Guangdong Province, China. You are warmly welcome to visit us whenever you are available!
2. Q: What is the raw material of your products?
A: As general, the raw material of steel code is Q235. Other steel is also available to clients’ requirements.
3. Q: What is the term of payment?
A: As general, 30% T/T down payment and balance before shipping.
4. Q: What is delivery time?
A: It depends on the order quantity and racking types. As general, within 25 days, for ordinary order quantity of Storage Pallet Racking System.
5. Q: Which port will be used as loading port?
A: Shenzhen,Guangzhou port, the closest port to us, is recommended strongly as loading port.
6. Q: May I know the status of my order?
A: Yes. We will send you information and photos at different production stage of your order. You can also get the latest information on our contract tracking system.
7. Q: Are samples available?
A: Yes. Short sections of samples could be provided, they are free of charge, but international courier costs to be borne by clients.
8. Q: How can I get your quick quotation on my pallet racking project?
A: As different clients and projects have different needs of racking dimensions and specification, as general, for quick quotation, we need to know following info:
Required Pallet Racking Dimension: Height*Depth*Length?
Number of Levels?
Loading Capacity of each level?
Racking Quantity?
If you are not very sure of above info, please just let us know your storage needs. Accordingly, we'll be happy to provide with our professional proposed racking solutions for your kind reference.
