Heavy Duty Cold Roll Steel Moving File Cabinets Shelf System With Floor Tracks

2-10 SETS
MOQ
Negotiation
Price
Heavy Duty Cold Roll Steel Moving File Cabinets Shelf System With Floor Tracks
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Rolling Lateral File Cabinet Furniture
Material: Metal
Specific Use: Filing Cabinet
Usage: Library,school,office,bank
Feature: Corrosion Protection
Raw Material: High Qulity Cold Roll Steel
Warranty: 3 Years On Normal Use
Structure: Knock Down
Highlight:

Heavy Duty Moving File Cabinets Shelf System

,

Cold Roll Steel Moving File Cabinets Shelf System

Basic Infomation
Certification: ISO9001/14001
Model Number: W-MFC2017526
Payment & Shipping Terms
Packaging Details: Professional & Saft packaging for oversea shipment
Delivery Time: 15-30 Days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100 SETS
Product Description

China Manufacturer Heavy duty Cold Roll Steel File Shelving Compact Mobile File Cabinet

Specification:

Shelf body

Stand Column

Cold-roll steel

1.5mm

GB708

Partition Whole body partition partition flange 25mm (reinforcing rib under the partition)

Cold-roll steel

1.0mm

GB708

Side plate

Cold-roll steel

1.0mm

GB708

Upper cover plate (whole body side plate dimension 300X100mm)

Cold-roll steel

1.0mm

GB708

Panel

Cold-roll steel

1.0mm

GB708

chassis

Main beam and whole frame board

(every wheelo frame board have six : 55mm beam bush hole. every hole have sealing

Hot rolled steel plate

3.0mm

GB710

pathway

Rail

High quality steel plate

Solid square tube

GB710

Rail box

High quality steel plate

26X95mm
Thickness 3.0

GB710

Pathway

High quality steel plate

50X185
Thickness 3.0

GB710

Transmission part

Handle crank

ZG45

Bothway overload clutch

double axis transmission

GB1285

Transmission shaft

Solid core 45 steel

Φ20

GB699

Linkage rail

Seamless steel tube

Φ20X2.5

GB699

Bearing

Precision bearing

HR6204

GB/T
307.3-2005

Chain wheel

ZG45



GB1135

Chain

FR420

Φ8.5, pitch12.7

breaking force 1800kg

GB1244

Idler wheel

HT20-40

Cast iron

Gb11351



Sealing rubber strip

Magnetic fluid sealant





Dust shield

Cold-roll steel

1.0

Gb710

Barb

Hot rolled steel plate

3.0mm

Gb711


Features


. Widely used in archives, library, government, bank and company documents center
. Instruction in package enables your installing very easy and fast
. Consists of fixed shelves installed on mobile chassis at bottom
. Every rack own transmission equipment
. Being compact can utilize room adequately and fully enclosed
. Only one aisle to be used, highest space utilization, nice and practical
. Sealing better, and can be manually and automatically operated
. Neat/elegant for file storage

Description:


Compact Mobile Filing Cabinet is a cost effective way of increasing storage capacity and utilizing valuable floor space, which can double storage capacity compared to conventional static shelving.
It is widely used in offices for file storage and are designed to be easily re-located with no floor fixing. It moves along floor tracks allowing the aisle to be moved so that the required shelves can be accessed, so only one aisle is needed.
Our Services
. Factory price with high quality
. OEM /ODM are available.
. Fast delivery.
. ISO,CE certified, one stop solution service for your project.
. Perfect design Exquisite technology, strict management, sincere service.
Heavy Duty Cold Roll Steel Moving File Cabinets Shelf System With Floor Tracks 0Heavy Duty Cold Roll Steel Moving File Cabinets Shelf System With Floor Tracks 1
